Cartridge Valves

Cavity T-2A Port Configuration 3 Port Maximum Pressure 5000 psi

Cavity T-2A Port Configuration 3 Port Maximum Pressure 5000 psi

Cavity T-2A Adjustment Range 1000-4000PSI w/25PSI Check (70-280 Bar w/1.7 Bar Check) Pilot Ratio 3:1 Capacity 30 gpm Maximum Recommended  3075 psi Maximum Pressure 4000 psi

Cavity T-17A Adjustment Range 1000-4000PSI w/25PSI Check (70-280 Bar w/1.7 Bar Check) Pilot Ratio 3:1 Capacity 60 gpm Maximum Recommended  3075 psi Maximum Pressure 4000 psi

Cavity T-2A Adjustment Range 2000-5000PSI w/25PSI Check (140-350 Bar w/1.7 Bar Check) Pilot Ratio 2.3:1 Capacity 30 gpm Maximum Recommended  3850 psi Maximum Pressure 5000 psi

Cavity T-3A Adjustment Range 100-3000PSI (7-210 Bar) Capacity 50 gpm Maximum Operating Pressure 5000 psi

Cavity T-10A Adjustment Range 100-3000PSI (7-210 Bar) Capacity 25 gpm Maximum Operating Pressure 5000 psi

Cavity T-5A Cracking Pressure 50PSI (3.5 Bar) Capacity 40 gpm Maximum Operating Pressure 5000 psi

Cavity T-5A Cracking Pressure 4PSI (0.3 Bar) Capacity 40 gpm Maximum Operating Pressure 5000 psi

Cavity T-17A Cracking Pressure 75PSI (5 Bar) Capacity 80 gpm Pilot Ratio 1.8:1 Maximum Operating Pressure 5000 psi

Cavity T-2A Cracking Pressure 75PSI (5 Bar) Capacity 40 gpm Pilot Ratio 1.8:1 Maximum Operating Pressure 5000 psi
