STANDARD HYDRAULIC POWERPACK
TYPE FPS

This range of hydraulic power pack are design to be constructed from a standard range of modular components, to ensure a clear specification is created, simple assembly which will ensure it can be maintain in the most demanding of industrial applications. All the parts have been selected carefully to ensure quality competitive range of hydraulic power packs.

This range of power packs are specially designed to offer a wide range of motors, 0.55 to 22 kw, flow rates up to 100 litres per minute and pressures up to 250 bar, which will cover most standard applications.

We have a wide range of pumps, Group 1, 2 and 3, which give a smooth flow, they are based on the European standard, with shafts having a 1:8 taper, mounting 4 bolt type, with group 2 and 3 having cast iron mountings foe extra strength.
All power packs have suction and return line filtration, 25 microns with return line filters and 90 micron suction filters as standard. Higher level of filtration can be provided to increase cleanness of oil if required.

The AC motor range are IP55 rated, 4 pole 3 phase 380/440 volts, multi mounting B35 as standard. Other motor can be utilised if required with different voltages, motor poles, and anti-condensation heaters and EX protection.

A wide range of valves can be mounted on the FPS range of power packs to create numerous hydraulic circuit which should suit most applications.

However, if our standard power pack range FPS, does not offer you the features required, we are able to design and build competitively a hydraulic system to meet your specification.

_______________________________________________________________________________________________________________







Group 1



Group 2



Group 3


 Pump CC/Rev
2.5cc 4.2cc 6.1cc   6.3cc 8.3cc 10cc 11cc 15cc 19cc 25cc   32cc 36cc 42cc 46cc 50cc 55cc 60cc

Flow LPM
3.65 6.09 8.84   9.13 12.03 14.50 15.95 21.75 27.55 36.25   46.40 52.20 60.90 66.70 72.50 79.75 87.00
KW    TANK SIZES AVAILABLE LITRES
0.55 90 54 37   36 27 22                         18
1.10 164  99 67   65 49 41 37 27 21                   18 30
1.50   147 101    98 74 62 56 41 32 24                 18 30
2.20     149   144 109 91 82 60 47 36   28 25 21 19 18 16 15   30 60
3.00     203   197 149 124 112 82 65 49   38 34 29 26 24 22 20   30 60
4.00           199 165 150 110 87 66   51 45 39 35 33 30 27   30 60 80 100
5.50                206 151 119 91    71 63 54 49 45 41 37     60 80 100
7.50                  206 163 124    96 86 73 67 62 56 51     60 80 100 150
10.50                      176    135 120 103 95 86 78 72         100 150 180 210 250
15.00                          193 172 147 134 124 112 103         100 150 180 210 250
18.50                             182 166 143 139 127           150 180  210 250
22.00                                197  182 165 151               210 250
  MAX ACHIEVABLE PRESSURE (BAR)
Motor Selection Chart   Pump Selection Chart
Motor No Motor Power Frame Size   Pump No DISPLACEMENT
CC/REV		 FLOW AT 1450
RPM L/MIN		 MAXIMUM PRESSURE
BAR
 A  0.55  D80    2F  2.50  3.65  250
 B  0.75  D80   4F  4.20  6.09  250
 C  1.1  D90S   6F  6.10  8.84  250
 D 1.5   D90L
 E  2.2  D100L    12F  6.30 9.13  250
 F  3  D100L    13F 8.30  12.03  250
 G  4  D112M    14F 10.00  14.50  250
 H  5.5  D132S    15F 11.00  15.95  250
 I  7.5  D132M   16F  15.00  21.75  250
J   11  D160M   17F  19.00  27.55  250
K   15  D160L   19F 25.00  36.25  160
L   18  D180M
M   22  D180L   22F  32.00  46.40  250
        23F 36.00 52.20 250
        24F 42.00 60.92 230
        25F 46.00 66.70 230
        26F 50.00 72.50 200
        27F 55.00 79.75 200
        28F 60.00 87.00 180
TANK USEABLE CAPACITY A B C D Q M MOTOR RANGE ACTUAL VOLUME
18 420 330 300   360 270 0.55 KW TO 1.5 KW 41.8
30 465 380 330   405 320 1.10 KW TO 4.0 KW 58.31
60 605 475 380   545 415 2.2 KW TO 7.5 KW  109.2
80 605 475 465   545 415 4.00 KW TO 7.5 KW 133.62
100 680 580 500   620 520 4.00 KW TO 15 KW 197.2
150 680 580 610   620 520 7.5 KW TO 18.5 KW 240.58
180 810 640 545   750 580 10.5 KW TO 18.5 KW 282.52
210 810 640 600   750 580 10.5 KW TO 22 KW 306.63
250 810 640 700   750 580 10.5 KW TO 22 KW 362.88

Powerpack Ordering Code
