HYDRAULIC CYLINDERS WITH PIN HOLES
- Part Number:
- FC1 SERIES
Description
FC1 HYDRAULIC CYLINDERS
DOUBLE / SINGLE* ACTING CYLINDER (* = WITH USE OF BREATHER)
MAX PRESSURE = 210 BAR (WORKING) / 250 BAR (MAXIMUM)
MAX SPEED = 0.5 M/S
OPERATING TEMPERATURE (°C) = +80°C / -25°C
TUBE MATERIAL = STEEL - ST52.3 - DIN2393 - ISO H9
ROD MATERIAL = STEEL - UNI C45 (SAE 1045) - 25 MICRON (±5) - EN8 GRADE
|
ORDER |
BORE |
D |
R |
L |
+STROKE |
P |
E |
F |
| FC13220(STROKE) | 32 | 42 | 20 | 138 |
CUSTOMER
REQUIREMENT |
1/4" | 16.25 | 31 |
| FC14020(STROKE) | 40 | 50 | 137 | |||||
| FC14025(STROKE) | 25 | |||||||
| FC15025(STROKE) | 50 | 60 | 162 | 3/8" | 20.25 | 36 | ||
| FC15030(STROKE) | 30 | 174 | ||||||
| FC16030(STROKE) | 60 | 70 | 193 | 25.25 | 46 | |||
| FC16035(STROKE) | 35 | |||||||
| FC16040(STROKE) | 40 | |||||||
| FC16340(STROKE) | 63 | 73 | ||||||
| FC17035(STROKE) | 70 | 80 | 35 | |||||
| FC17040(STROKE) | 40 | 203 | ||||||
| FC18040(STROKE) | 80 | 90 | 221 | 1/2" | 30.25 | 56 | ||
| FC18050(STROKE) | 50 | |||||||
| FC19050(STROKE) | 90 | 105 | 239 | 40.25 | 66 | |||
| FC11050(STROKE) | 100 | 115 | 244 | |||||
| FC11060(STROKE) | 60 |
