HYDRAULIC CYLINDERS WITH PIN BOSSES
- Part Number:
- FC2 SERIES
Description
FC2 HYDRAULIC CYLINDERS
DOUBLE / SINGLE* ACTING CYLINDER (* = WITH USE OF BREATHER)
MAX PRESSURE = 210 BAR (WORKING) / 250 BAR (MAXIMUM)
MAX SPEED = 0.5 M/S
OPERATING TEMPERATURE (°C) = +80°C / -25°C
TUBE MATERIAL = STEEL - ST52.3 - DIN2393 - ISO H9
ROD MATERIAL = STEEL - UNI C45 (SAE 1045) - 25 MICRON (±5) - EN8 GRADE
|
ORDER |
BORE |
D |
R |
L |
+STROKE |
P |
E |
F |
F1 |
H |
H1 |
C |
C1 |
| FC23220(STROKE) | 32 | 42 | 20 | 152 |
CUSTOMER
REQUIREMENT |
1/4" | 16.25 | 15.5 | 15.5 | 35 | 35 | 30 | 60 |
| FC24020(STROKE) | 40 | 50 | 147 | ||||||||||
| FC24025(STROKE) | 25 | ||||||||||||
| FC25025(STROKE) | 50 | 60 | 167 | 3/8" | 20.25 | 18 | 18 | 40 | 40 | 40 | 70 | ||
| FC25030(STROKE) | 30 | 179 | |||||||||||
| FC26030(STROKE) | 60 | 70 | 193 | 25.25 | 23 | 23 | 50 | 50 | 50 | 80 | |||
| FC26035(STROKE) | 35 | ||||||||||||
| FC26040(STROKE) | 40 | ||||||||||||
| FC26340(STROKE) | 63 | 73 | 191 | ||||||||||
| FC27035(STROKE) | 70 | 80 | 35 | 188 | |||||||||
| FC27040(STROKE) | 40 | 198 | |||||||||||
| FC28040(STROKE) | 80 | 90 | 211 | 1/2" | 30.25 | 28 | 28 | 60 | 60 | 60 | 110 | ||
| FC28050(STROKE) | 50 | ||||||||||||
| FC29050(STROKE) | 90 | 105 | 221 | 40.25 | 33 | 33 | 70 | 70 | 70 | 130 | |||
| FC21050(STROKE) | 100 | 115 | |||||||||||
| FC21060(STROKE) | 60 |
