HYDRAULIC CYLINDERS WITH CLEVIS
- Part Number:
- FC4 SERIES
Description
FC4 HYDRAULIC CYLINDERS
DOUBLE / SINGLE* ACTING CYLINDER (* = WITH USE OF BREATHER)
MAX PRESSURE = 210 BAR (WORKING) / 250 BAR (MAXIMUM)
MAX SPEED = 0.5 M/S
OPERATING TEMPERATURE (°C) = +80°C / -25°C
TUBE MATERIAL = STEEL - ST52.3 - DIN2393 - ISO H9
ROD MATERIAL = STEEL - UNI C45 (SAE 1045) - 25 MICRON (±5) - EN8 GRADE
|
ORDER |
BORE |
D |
R |
L |
+STROKE |
P |
E |
F |
F1 |
H |
H1 |
C |
C1 |
| FC43220(STROKE) | 32 | 42 | 20 | 215 |
CUSTOMER
REQUIREMENT |
1/4" | 16.2 | 34 | 25 | 35 | 35 | 16 | 20 |
| FC44020(STROKE) | 40 | 50 | 210 | ||||||||||
| FC44025(STROKE) | 25 | ||||||||||||
| FC45025(STROKE) | 50 | 60 | 236 | 3/8" | 20.25 | 40 | 30 | 40 | 45 | 20 | 25 | ||
| FC45030(STROKE) | 30 | 248 | |||||||||||
| FC46030(STROKE) | 60 | 70 | 262 | 25.25 | 45 | 35 | 50 | 50 | 25 | 30 | |||
| FC46035(STROKE) | 35 | ||||||||||||
| FC46040(STROKE) | 40 | ||||||||||||
| FC46340(STROKE) | 63 | 73 | 260 | ||||||||||
| FC47035(STROKE) | 70 | 80 | 35 | 257 | |||||||||
| FC47040(STROKE) | 40 | 267 | |||||||||||
| FC48040(STROKE) | 80 | 90 | 285 | 1/2" | 30.25 | 50 | 45 | 60 | 60 | 30 | 35 | ||
| FC48050(STROKE) | 50 | ||||||||||||
| FC49050(STROKE) | 90 | 105 | 320 | 40.25 | 70 | 60 | 80 | 70 | 40 | 40 | |||
| FC41050(STROKE) | 100 | 115 | |||||||||||
| FC41060(STROKE) | 60 |
