HYDRAULIC CYLINDERS WITH BEARING MOUNT
- Part Number:
- FC3 SERIES
Description
FC3 HYDRAULIC CYLINDERS
DOUBLE / SINGLE* ACTING CYLINDER (* = WITH USE OF BREATHER)
MAX PRESSURE = 210 BAR (WORKING) / 250 BAR (MAXIMUM)
MAX SPEED = 0.5 M/S
OPERATING TEMPERATURE (°C) = +80°C / -25°C
TUBE MATERIAL = STEEL - ST52.3 - DIN2393 - ISO H9
ROD MATERIAL = STEEL - UNI C45 (SAE 1045) - 25 MICRON (±5) - EN8 GRADE
|
ORDER |
BORE |
D |
R |
L |
+STROKE |
P |
E |
F |
F1 |
H |
H1 |
C |
C1 |
| FC33220(STROKE) | 32 | 42 | 20 | 191 |
CUSTOMER
REQUIREMENT |
1/4" | 16 | 35 | 35 | 46 | 48 | 14 | 17.5 |
| FC34020(STROKE) | 40 | 50 | 186 | ||||||||||
| FC34025(STROKE) | 25 | ||||||||||||
| FC35025(STROKE) | 50 | 60 | 207 | 3/8" | 20 | 38 | 38 | 53 | 50 | 16 | 19 | ||
| FC35030(STROKE) | 30 | 219 | |||||||||||
| FC36030(STROKE) | 60 | 70 | 237 | 25 | 45 | 45 | 64 | 55 | 20 | 23 | |||
| FC36035(STROKE) | 35 | ||||||||||||
| FC36040(STROKE) | 40 | ||||||||||||
| FC36340(STROKE) | 63 | 73 | 235 | ||||||||||
| FC37035(STROKE) | 70 | 80 | 35 | 232 | |||||||||
| FC37040(STROKE) | 40 | 242 | |||||||||||
| FC38040(STROKE) | 80 | 90 | 257 | 1/2" | 30 | 51 | 51 | 73 | 65 | 22 | 28 | ||
| FC38050(STROKE) | 50 | ||||||||||||
| FC39050(STROKE) | 90 | 105 | 293 | 40 | 69 | 69 | 92 | 100 | 28 | 35 | |||
| FC31050(STROKE) | 100 | 115 | |||||||||||
| FC31060(STROKE) | 60 |
